Cast resin joint, Branch Y, 3 x 1.5mm? to 5 x 10mm?, L=205mm, 490 ml, Polyurethane resin (PUR) green
Product Description
| Application |
RELICON branch joints are made for installations in low-voltage electrical networks. They are suitable for jointing on polymeric cables and wires made of PVC, XLPE, PE, EPR and utility cables. Application: Connections in industrial buildings, power supply in the ground, outdoors and underwater. |
| Colour | Green (GN) |
| Content |
Cast resin PUR 33 Two-chamber pouch, transparent Moulding shells, transparent SF-system and nozzle Protective gloves, emery cloth, installation instructions HelaTape vinyl electrical tape |
| Material | Polyurethane resin (PUR) |
| No. of Wires | 5 |
| PART DESCRIPTION | Y-1 / SF-PUR-GN |
| Package Content | 1Set |
| Package Content packed in | set |
| Product Family | RELICON Y-Line SF with PUR 33 |
| Product Group | Branch cable joints |
| Short Description | Branch joint Y-1 / SF 3×1,5 to 5×10, 3×1,5 to 5×6 |
| Type | Y-1 / SF |
| Variant | Cast resin |
| Weight/Unit | 0.836kg |
| Dimensions | 205 × 0.205 × 70 in |
|---|
