Cast resin joint, Parallel P, 4 x 16mm? to 5 x 25mm?, L=300mm, 955 ml, Polyurethane resin (PUR) green
Product Description
| Application |
The parallel branch joint PA is a universal straight-through and branch joint. Depending on the connector, it can be used for single and double branches. They are suitable for jointing on polymeric cables and wires made of PVC, XLPE, PE, EPR and utility cables. Application: In low-voltage electrical networks as well as for signal and communication cables. For power supply lines for outdoor lighting and for cable repairs. In general connections in industrial buildings, power supply underground, outdoors and under water. |
| Colour | Green (GN) |
| Content |
Cast resin PUR 33 In a two-chamber pouch Transparent, one-piece moulding shell Foam seal, protective gloves, emery cloth Cleaning cloth, installation instructions SF-nozzle (two-chamber pouch) |
| Material | Polyurethane resin (PUR) |
| No. of Wires | 4 |
| PART DESCRIPTION | PA-12 / SF-PUR-GN |
| Package Content | 1Set |
| Package Content packed in | set |
| Product Family | RELICON PA-12 with PUR 33 |
| Product Group | Parallel cable branch joints |
| Short Description | Parallel branch joint PA 12 75/300 |
| Type | PA-12 / SF |
| Variant | Cast resin |
| Weight/Unit | 1.398kg |
| Dimensions | 300 × 0.24 × 75 in |
|---|
