Product Description
| Code | SPCM081313G |
| GTIN | 6418677166372 |
| Name | Enclosure PC Ensto Cubo S |
| Size 75 x 125 x 125 mm, 50 mm base, metric knockouts, grey cover, PC | |
| Description | Ensto Cubo S is a series of small to medium size enclosures available with knockouts or plain sides. The base of the enclosures is equipped with unique slots for printed circuit boards. |
| Vendor | Ensto Building Systems Finland Oy |
| Brand | Ensto Cubo S |
| Benefits |
|
Certificates
| Standards: | GOST R,EN 62208 |
Colors
| Color: | Grey |
Dimensions
| Volume : | 117.19 cm³ |
| Inner depth: | 110.5 mm |
| Length: | 125 mm |
| Outer base depth: | 50 mm |
| Width: | 75 mm |
| Height: | 125 mm |
| Outer cover height: | 75 mm |
| Size: | 75 x 125 x 125 mm |
| Weight: | 0.3 kg |
Features
| Knockouts: | 2 x M16/25 + 6 x M12/20 |
Material
| Base: | Fiberglass reinforced polycarbonate |
| Cover: | Polycarbonate |
| Cover screws: | Polyamide |
| Gasket: | Polyurethane |
| Material: | Polycarbonate |
Mechanical
| Impact strength: | IK 08 |
Others
| Content: | Enclosure base, cover, cover screws, mounting screws |
| ETIM Class: | EC000261 |
Ratings
| Degree of protection: | IP66/IP67 |
| Flammability rating: | UL 746C 5 inch flame test |
Temperatures
| Operating temperature: | -40 ... 80 °C |
| Short term temperature range: | -40 ... 120 °C |
Electrical values
| Rated insulation voltage AC: | 1000 V |
| Rated insulation voltage DC: | 1500 V |
| Height: | 125 mm |
| Depth: | 125 mm |
| Material: | Plastic |
| Material quality: | Other |
| Surface finishing: | Untreated |
| Colour: | Grey |
| RAL-number: | 7035 |
| With mounting plate: | No |
| Suitable for outdoor set-up: | Yes |
| With glazed door: | No |
| Impact strength: | IK08 |
| Degree of protection (IP): | IP67,EV006423 |
| Package size: | 1 pcs |
| Depth: | 125 mm |
| Width: | 75 mm |
| Height: | 125 mm |
| Weight: | 0.4 kg |
| Volume: | 1.171875 l |
| Package size: | 9 pcs |
| Depth: | 383 mm |
| Width: | 258 mm |
| Height: | 173 mm |
| Weight: | 3.842 kg |
| Volume: | 17.094822 l |
| Package size: | 486 pcs |
| Depth: | 1200 mm |
| Width: | 800 mm |
| Height: | 1188 mm |
| Weight: | 232.468 kg |
| Volume: | 1140.48 l |
