Enclosure PC 75 x 125 x 60 mm

When choosing a protective enclosing, it is necessary understand the operating principles of the equipment that will be installed in the enclosure and the equipment operating conditions. Accurate identification of the required enclosure parameters include: material, degree of protection, flammability and certificates material, degree of protection, flammability and certificates.

View More

Product Description

Code SPCM081306G
GTIN 6438100101411
Name Enclosure PC Ensto Cubo S
  Size 75 x 125 x 60 mm, 50 mm base, metric knockouts, grey cover, PC
Description Ensto Cubo S is a series of small to medium size enclosures available with knockouts or plain sides. The base of the enclosures is equipped with unique slots for printed circuit boards.
Vendor Ensto Building Systems Finland Oy
Brand Ensto Cubo S
Benefits
  • Greater
  • material thickness
  • Fibreglass-reinforced bases
  • Cost-efficient mold modifications
  • Lightweight products
  • Durability and easy maintenance

Certificates

Standards: EN 62208,GOST R

Colors

Color: Grey

Dimensions

Volume : 56.25 cm³
Inner depth: 45.5 mm
Length: 60 mm
Outer base depth: 50 mm
Width: 75 mm
Height: 125 mm
Outer cover height: 10 mm
Size: 75 x 125 x 60 mm
Weight: 0.1594 kg

Features

Knockouts: 2 x M16/25 + 6 x M12/20

Material

Base: Fiberglass reinforced polycarbonate
Cover: Polycarbonate
Cover screws: Polyamide
Gasket: Polyurethane
Material: Polycarbonate

Mechanical

Impact strength: IK 08

Others

Content: Enclosure base, cover, cover screws, mounting screws
ETIM Class: EC000261

Ratings

Degree of protection: IP66/IP67
Flammability rating: UL 746C 5 inch flame test

Temperatures

Operating temperature: -40 ... 80 °C
Short term temperature range: -40 ... 120 °C

Electrical values

Rated insulation voltage AC: 1000 V
Rated insulation voltage DC: 1500 V


Etim

Height: 125 mm
Depth: 60 mm
Material: Plastic
Material quality: Other
Surface finishing: Untreated
Colour: Grey
RAL-number: 7035
With mounting plate: No
Suitable for outdoor set-up: Yes
With glazed door: No
Impact strength: IK08
Degree of protection (IP): IP67,EV006423


Plastic bag

Package size: 1 pcs
Depth: 60 mm
Width: 75 mm
Height: 125 mm
Weight: 0.259 kg
Volume: 0.5625 l

Carton (Default package)

Package size: 18 pcs
Depth: 383 mm
Width: 258 mm
Height: 173 mm
Weight: 4.911 kg
Volume: 17.094822 l

Pallet package

Package size: 972 pcs
Depth: 1200 mm
Width: 800 mm
Height: 1188 mm
Weight: 290.205 kg
Volume: 1140.48 l
