Product Description
Product name: Insulated Joint Ferrules
Material Terminal Body: Copper
Plating: Tin
Color: Red, yellow, blue, green, black, grey, orange
Usage: Connecting Cable
Feature: Well-made / insulation protection,
certification: RoHS
Application field: Electrician electrical/Industrial Equipment
Surface treatment: According to customer needs, tin plating, nickel plating, silver plating, gold plating
Test: High temperature, Salt spray, waterproof
Package: 100pcs / Bag
| Long Full Insulating Middle Joint | |||||||||
| Item No. | A.W.G | Lead Section | Dimension（mm） | Max.current | Color | Description | |||
| mm2 | I | dØ | DØ | L | |||||
| BV 0.5 | 26-22 | 0.2-0.5 | 12.0 | 1.3 | 3.3 | 22.0 | 15A | Red | PVC Middle Connector Long Type Material: Copper Insulating Materials: PVC |
| BV 1.2 | 22-16 | 0.5-1.5 | 15.0 | 1.7 | 4.3 | 25.0 | 19A | Red | |
| BV 2 | 16-14 | 1.5-2.5 | 15.0 | 2.3 | 4.9 | 25.0 | 27A | Blue | |
| BV 3.5 | 14-12 | 2.5-4 | 15.0 | 3.0 | 6.3 | 25.0 | 36A | Black | |
| BV 5.5 | 12-10 | 4-6 | 15.0 | 3.4 | 6.7 | 25.0 | 48A | Yellow | |
| BV 8 | #8 | 6-10 | 21.0 | 4.5 | 8.5 | 32.0 | 62A | Red | |
| BV 14 | #4 | 10-16 | 26.0 | 5.8 | 10.5 | 42.0 | 88A | Blue | |
| BV 22 | #4 | 16-25 | 29.0 | 7.7 | 13.0 | 50.0 | 115A | Yellow | |
| BV 38 | #2 | 35-50 | 32.0 | 9.4 | 15.3 | 55.0 | 160A | Red | |
