Product Description
Product name: Pin Shaped Insulated Terminals
Material Terminal Body: Copper
Plating: Tin
Color: Red, yellow, blue, green, black, grey, orange
Usage: Connecting Cable
Feature: Well-made / insulation protection,
certification: RoHS
Application field: Electrician electrical/Industrial Equipment
Surface treatment: According to customer needs, tin plating, nickel plating, silver plating, gold plating
Test: High temperature, Salt spray, waterproof
Package: 100pcs / Bag
| Pin-Shaped Pre-Insulating Terminal | |||||||
| Item No. | Dimension（mm） | Color | Description | ||||
| B | F | L | E | DØ | |||
| PTV 1.25-9 | 1.9 | 9.0 | 19.0 | 10.0 | 4.3 | Red | Lead Section：0.5~1.5mm2
A.W.G.:22~16 Max.current：IMAX=10A Materl：Copper Insulation：PVC Thickness：0.7mm |
| PTV 1.25-10 | 1.9 | 10.0 | 20.0 | ||||
| PTV 1.25-12 | 1.9 | 12.0 | 22.0 | ||||
| PTV 1.25-13 | 1.9 | 13.0 | 23.0 | ||||
| PTV 1.25-18 | 1.9 | 18.0 | 28.0 | ||||
| PTV 2-9 | 1.9 | 9.0 | 19.0 | 10.0 | 4.9 | Blue | Lead Section：1.5~2.5mm2
A.W.G.:16~14 Max.current：IMAX=27A Materl：Copper Insulation：PVC Thickness：0.8mm |
| PTV 2-10 | 1.9 | 10.0 | 20.0 | ||||
| PTV 2-12 | 1.9 | 12.0 | 22.0 | ||||
| PTV 2-13 | 1.9 | 13.0 | 23.0 | ||||
| PTV 2-18 | 1.9 | 18.0 | 28.0 | 13.0 | 6.7 | Yellow | Lead Section：4~6mm2
A.W.G.:12~10 Max.current：IMAX=48A Materl：Copper Insulation：PVC Thickness：1.0mm |
| PTV 5.5-10 | 2.8 | 10.0 | 23.8 | ||||
| PTV 5.5-13 | 2.8 | 13.0 | 26.8 | ||||
| PTV 5.5-18 | 2.8 | 18.0 | 31.8 | ||||
