Tube Insulated Terminal

Part No:E-XXXX

Description

Product Description

Product name: Tube Insulated Terminal/ Insulated Cord End Terminal

Material: Copper, Fire resistant PVC

Surface coating: Tin Plated

Color: Red, yellow, blue, green, black, grey, orange

Usage: Connecting Cable

Feature: Fixable, good elasticity, unable broken, high durability

Standard: RoHS, CE

Long-term temperature ℃: 105

Short-term temperature ℃: 120

Quickly understand the model
Take VE1008 as an example
VE: Product series
10: suitable for 1.0 square millimeter wire
08: Exposed length of copper tube
Metal material: copper & brass
(Default copper.
Please contact if you need brass.
Brass price is more advantageous)
Insulator material: flame retardant PP

Umax:105℃ Ui=300V Material: Copper Pipe Insulating Material: Nylon
ITEM NO.	DIMENSION							Color for insulation
	F	L	W	DØ	CØ	A.W.G	mm²	sheath(Top)Germany
	mm	mm	mm	mm	mm	mm		(Bottom)France
E 0506	6	12	2.6	1.3	1	#22	0.5	Orange White
E 0508	8	14
E 0510	10	16
E 0512	12	18
E 7506	6	12.4	2.8	1.5	1.2	#20	0.75	White Blue
E 7508	8	14.6
E 7510	10	16.4
E 7512	12	18.4
E 1006	6	12.4	3.0	1.7	1.2	#18	1	Yellow Red
E 1008	8	14.6
E 1010	10	16.4
E 1012	12	18.4
E 1508	8	14.6	3.5	2	1.7	#16	1.5	Red Black
E 1510	10	16.4
E 1512	12	18.4
E 1518	18	24.4
E 2508	8	15.2	4	2.6	2.3	#14	2.5	Blue Grey
E 2510	10	17.2
E 2512	12	19.2
E 2518	18	25.2
E 4009	9	16.5	4.4	3.2	2.8	#12	4	Grey Orange
E 4012	12	19.5
E 4018	18	25.5
E 6010	10	18	6.3	3.9	3.5	#10	6	Black Green
E 6012	12	20
E 6018	18	26
E 10-12	12	21.5	7.6	4.9	4.5	#7	10	Ivory Brown
E 10-18	18	27.5
E 16-12	12	22.2	8.8	6.2	5.8	#5	16	Green Ivory
E 16-18	18	28.2
E 25-16	16	29	11.2	7.9	7.5	#4	25	Brown Black
E 25-22	22	35
E 35-16	16	30	12.7	8.7	8.3	#2	35	Dust-colour
E 35-25	25	39
E 50-20	20	36	15.3	10.9	10.3	#1	50	Olives color
E 50-25	25	41
